Huawei SUN2000-36KTL User Manual

SUN2000-(33KTL-A, 36KTL, 42KTL)
User Manual
8 Maintenance
Issue 07 (2018-05-04)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
95
Alarm
ID
Alarm
Name
Alarm
Severity
Possible Cause
Suggestion
Residual
Current
The insulation resistance against
the PGND cable at the input side
decreases when the SUN2000 is
running, which causes an
excessively high residual
current.
abnormal temporarily. The
SUN2000 automatically recovers
after fault is rectified.
2. If the alarm occurs repeatedly or
persists, check whether the
impedance between the PV string
and the ground is excessively low.
321
Cabinet
Overtempe
rature
Major
Cause ID = 1

The SUN2000 is installed in
a place with poor ventilation.

The ambient temperature
exceeds the upper threshold.

The internal fan works
abnormally.
1. Check the ventilation and ambient
temperature of the SUN2000
installation position.
2. If the ventilation is poor or the
ambient temperature exceeds the
upper threshold, improve the
ventilation and heat dissipation.
3. If the ventilation and ambient
temperature both meet
requirements, contact Huawei
technical support.
322
Abnormal
SPI
Communic
ation
Major
Cause ID = 1
An unrecoverable fault occurs
on a circuit inside the SUN2000.
Turn off the AC output switch and DC
input switch. Then turn on the AC
output switch and DC input switch
after 5 minutes. If the fault persists,
contact Huawei technical support.
326
Abnormal
Grounding
Major
Cause ID = 1

The neutral wire or PGND
cable does not connect to the
SUN2000.

The SUN2000 output side
does not connect to an
isolation transformer when
the PV string output is
grounded.
1. Check that the neutral wire or
PGND cable properly connects to
the inverter.
2. If the PV string output is
grounded, check that the SUN2000
output side connects to an isolation
transformer.
400
System
Fault
Major
Cause ID = 1/3/21/23/27
An unrecoverable fault occurs
on a circuit inside the SUN2000.
Turn off the AC output switch and DC
input switch. Then turn on the AC
output switch and DC input switch
after 5 minutes. If the fault persists,
contact Huawei technical support.
410
Abnormal
Auxiliary
Power
Major
Cause ID = 4
The sampling control board has
an abnormal voltage, which may
be caused by the following:

The internal power chip of
the sampling control board is
faulty.

The detection circuit
becomes faulty.
1. When the alarm is generated, the
SUN2000 shuts down
automatically. When the fault is
rectified, the SUN2000 starts
automatically.
2. If the alarm persists, contact
Huawei technical support.

Huawei SUN2000-36KTL Specifications

General

Purpose	Solar panel
Efficiency	98.8 %
Output power	36000 W
Weatherproof	Yes
Certification	EN 62109-1/-2, IEC 62109-1/-2, EN 50530, IEC 62116, IEC 60068, IEC 61683
Input voltage	250 - 1100 V
Output voltage	220/380, 230/400, 277/480 V
Input frequency	- Hz
Power supply type	Outdoor
Power current type	DC-to-AC
Adjustable output voltage	-
Power protection features	Over current
International Protection (IP) code	IP65
Product color	White
Quantity per pack	1 pc(s)
Operating temperature (T-T)	-25 - 60 °C
Operating relative humidity (H-H)	0 - 100 %

Weight and Dimensions

Depth	283 mm
Width	930 mm
Height	550 mm
Weight	62000 g
