SUN2000-(33KTL-A, 36KTL, 42KTL)
User Manual
4 System Installation
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
26
Figure 4-7 Stacked installation mode (not recommended)
4.3.2 Moving the Inverter
Context
To prevent device damage and personal injury, keep balance when moving the SUN2000
because the SUN2000 is heavy.
Do not place the SUN2000 with its wiring terminals at the bottom contacting the floor or
any other object because the terminals are not designed to support the weight of the
SUN2000.
When placing the SUN2000 on the floor, put foam or paper under the SUN2000 to protect
its cover.
Procedure
Step 1 Arrange two persons to hold the handles on both sides of the SUN2000.

Other manuals for Huawei SUN2000-36KTL

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Huawei SUN2000-36KTL and is the answer not in the manual?

Huawei SUN2000-36KTL Specifications

General IconGeneral
PurposeSolar panel
Efficiency98.8 %
Output power36000 W
WeatherproofYes
CertificationEN 62109-1/-2, IEC 62109-1/-2, EN 50530, IEC 62116, IEC 60068, IEC 61683
Input voltage250 - 1100 V
Output voltage220/380, 230/400, 277/480 V
Input frequency- Hz
Power supply typeOutdoor
Power current typeDC-to-AC
Adjustable output voltage-
Power protection featuresOver current
International Protection (IP) codeIP65
Product colorWhite
Quantity per pack1 pc(s)
Operating temperature (T-T)-25 - 60 °C
Operating relative humidity (H-H)0 - 100 %
Weight and Dimensions IconWeight and Dimensions
Depth283 mm
Width930 mm
Height550 mm
Weight62000 g
