Huawei SUN2000-36KTL User Manual

SUN2000-(33KTL-A, 36KTL, 42KTL)
User Manual
10 Technical Specifications
Issue 07 (2018-05-04)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
100
Item
SUN2000-33KTL-
A
SUN2000-36KTL
SUN2000-42KTL
Note a: The maximum active power is determined by PQ mode, which can be set on the
SUN2000 app, SmartLogger, or NetEco. If PQ mode 1 is selected, the maximum active
power equals the maximum apparent power. If PQ mode 2 is selected, the maximum active
power equals the rated active power.
Note b: The rated output voltage depends on Grid code, which can be set on the SUN2000
app, SmartLogger, or NMS.
Note c: Choose whether to connect the neutral wire to the SUN2000-33KTL-A and
SUN2000-36KTL based on the application scenario. When they are used in the scenarios
without the neutral wire, set Output mode to Three-phase, three-wire. When they are
used in the scenarios with the neutral wire, set Output mode to Three-phase, four-wire.
Protection
Item
SUN2000-33KTL-
A
SUN2000-36KTL
SUN2000-42KTL
Input DC switch
Supported
Anti-islanding
protection
Supported
Output overcurrent
protection
Supported
Input reverse
connection
protection
Supported
PV string fault
detection
Supported
DC surge protection
Type II
AC surge protection
Type II
Insulation resistance
detection
Supported
Residual current
monitoring unit
(RCMU)
Supported
Arc fault protection
(AFCI: arc fault
circuit interrupter)
Not supported
Optional
Not supported

Huawei SUN2000-36KTL Specifications

General

Purpose	Solar panel
Efficiency	98.8 %
Output power	36000 W
Weatherproof	Yes
Certification	EN 62109-1/-2, IEC 62109-1/-2, EN 50530, IEC 62116, IEC 60068, IEC 61683
Input voltage	250 - 1100 V
Output voltage	220/380, 230/400, 277/480 V
Input frequency	- Hz
Power supply type	Outdoor
Power current type	DC-to-AC
Adjustable output voltage	-
Power protection features	Over current
International Protection (IP) code	IP65
Product color	White
Quantity per pack	1 pc(s)
Operating temperature (T-T)	-25 - 60 °C
Operating relative humidity (H-H)	0 - 100 %

Weight and Dimensions

Depth	283 mm
Width	930 mm
Height	550 mm
Weight	62000 g
