Huawei SUN2000-36KTL User Manual

SUN2000-(33KTL-A, 36KTL, 42KTL)
User Manual
1 Safety Precautions
Issue 07 (2018-05-04)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2
Protect Labels

Do not tamper with any warning labels on the inverter enclosure because these labels
contain important information about safe operation.

Do not tamper with the nameplate on the inverter enclosure because it contains important
product information.
Installation

Ensure that the inverter is not connected to a power supply and is not powered on before
starting installation.

Ensure that there are no objects within 300 mm, 200 mm, 500 mm, 600 mm, and 1000
mm of the left, right, top, bottom, and front of the inverter, respectively. This is to allow
sufficient space for installation and heat dissipation. For ease of installation, ensure that
the inverter bottom is at most 730 mm above the floor. If you have any questions about
the distance, consult the local technical support engineers.

Ensure that the inverter is installed in a well ventilated environment.

Ensure that the inverter heat sinks are free from blockage.

Open the maintenance compartment door of the chassis before connecting cables. Do not
perform any operation on other components inside the chassis except connecting the PE
cable, AC power cables and communications cables.
Cable Connections
Before connecting cables, ensure that the inverter is secured in position and not damaged in
any way. Otherwise, electric shocks or fire may occur.

Ensure that all electrical connections comply with local electrical standards.

Obtain approval from the local utility company before using the inverter to generate
electricity in grid-tied mode.

Ensure that the cables used in a grid-tied PV system are properly connected and insulated,
meet all specification requirements.
Operation
High voltages may cause electric shocks result in serious injury, death or serious property
damage from inverter in operation. Strictly comply with the safety precautions in this
document and associated documents when operating the inverter.

Do not touch an energized inverter because the heat sink may be over 60ºC.

Follow local laws and regulations when operating the equipment.

Huawei SUN2000-36KTL Specifications

General

Purpose	Solar panel
Efficiency	98.8 %
Output power	36000 W
Weatherproof	Yes
Certification	EN 62109-1/-2, IEC 62109-1/-2, EN 50530, IEC 62116, IEC 60068, IEC 61683
Input voltage	250 - 1100 V
Output voltage	220/380, 230/400, 277/480 V
Input frequency	- Hz
Power supply type	Outdoor
Power current type	DC-to-AC
Adjustable output voltage	-
Power protection features	Over current
International Protection (IP) code	IP65
Product color	White
Quantity per pack	1 pc(s)
Operating temperature (T-T)	-25 - 60 °C
Operating relative humidity (H-H)	0 - 100 %

Weight and Dimensions

Depth	283 mm
Width	930 mm
Height	550 mm
Weight	62000 g
