Huawei SUN2000-36KTL User Manual

SUN2000-(33KTL-A, 36KTL, 42KTL)
User Manual
8 Maintenance
Issue 07 (2018-05-04)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
93
Alarm
ID
Alarm
Name
Alarm
Severity
Possible Cause
Suggestion
and the inverter protection is
triggered.
301
Abnormal
Grid
Voltage
Major
The grid voltage is beyond the
acceptable range. The possible
causes are as follows:

Cause ID = 4
The grid voltage is below the
specified lower threshold.

Cause ID = 16
The grid voltage exceeds the
specified upper threshold.

Cause ID = 19
The grid voltage has
exceeded the specified upper
threshold for 10 minutes.

Cause ID = 26
The grid voltage exceeds the
specified upper threshold.

Cause ID = 28
The three phases of the
power grid differ greatly in
voltage.

Cause ID = 29
1. The power grid
experiences an outage.
2. The AC circuit is
disconnected or AC
switch is OFF.

Cause ID = 31/32/33
The impedance of the output
phase wire A (cause ID =
31)/B (cause ID = 32)/C
(cause ID = 33) to the PE
cable is low or
short-circuited.
Cause ID = 4
1. If the alarm occurs accidentally,
the power grid may be abnormal
temporarily. The SUN2000
automatically recovers after
detecting that the power grid
becomes normal.
2. If the alarm occurs frequently,
check whether the grid voltage is
within the acceptable range. If no,
contact the local power operator. If
yes, log in to the SUN2000 app,
SmartLogger, or NMS to modify
the grid overvoltage and
undervoltage protection thresholds
with the consent of the local power
operator.
3. If the fault persists for a long time,
check the AC switch and AC
output power cable.
Cause ID = 16/19/26
1. Check whether the grid-tied
voltage exceeds the upper
threshold. If yes, contact the local
power operator.
2. If you have confirmed that the
grid-tied voltage exceeds the upper
threshold and obtained the consent
of the local power operator,
modify the overvoltage and
undervoltage protection thresholds.
3. Check whether the peak grid
voltage exceeds the upper
threshold.
Cause ID = 28
1. If the exception is caused by an
external fault, the SUN2000
automatically recovers after the
fault is rectified.
2. If the alarm persists and affects the
energy yield of the power station,
contact the local power operator.
Cause ID = 29
1. Check the AC voltage.
2. Check that the AC power cable is
securely connected and that the

Huawei SUN2000-36KTL Specifications

General

Purpose	Solar panel
Efficiency	98.8 %
Output power	36000 W
Weatherproof	Yes
Certification	EN 62109-1/-2, IEC 62109-1/-2, EN 50530, IEC 62116, IEC 60068, IEC 61683
Input voltage	250 - 1100 V
Output voltage	220/380, 230/400, 277/480 V
Input frequency	- Hz
Power supply type	Outdoor
Power current type	DC-to-AC
Adjustable output voltage	-
Power protection features	Over current
International Protection (IP) code	IP65
Product color	White
Quantity per pack	1 pc(s)
Operating temperature (T-T)	-25 - 60 °C
Operating relative humidity (H-H)	0 - 100 %

Weight and Dimensions

Depth	283 mm
Width	930 mm
Height	550 mm
Weight	62000 g
