Figure 8-2 Removing screws from the fan mounting plate
Step 2 Remove the cable tie, loosen the connector, disconnect the cable, and remove the
faulty fan.
Figure 8-3 Removing a faulty fan
Step 3 Install the new fan in the reverse order, bind the fan cable, and reconnect the
cable.
When binding the cable, you are advised to reserve 80 mm at one end of the
terminal, fold the rest of the cable and bind it in the middle using a cable tie, and
then bind the cable to the cable bridge.
SUN2000-(50KTL-ZHM3, 50KTL-M3)
User Manual 8 Maintenance
Issue 05 (2023-02-28) Copyright © Huawei Technologies Co., Ltd. 84
