Huawei SUN2000 M5 Series User Manual

Item SUN2000-15KTL-
ZHM5
SUN2000-17KTL-
ZHM5
SUN2000-20KTL-
ZHM5
SUN2000-25KTL-
ZHM5
MPPT voltage
range
200–1000 V
Full-load MPPT
voltage range
410–800 V 440–800 V 480–800 V 530–800 V
Rated input
voltage
600 V
Maximum
number of inputs
4
Number of
MPPTs
2
Note a: The maximum input voltage is the maximum DC input voltage that the inverter can
withstand. If the input voltage exceeds this value, the inverter may be damaged.
Output
Item
SUN2000-15KTL-
ZHM5
SUN2000-17KTL-
ZHM5
SUN2000-20KTL-
ZHM5
SUN2000-25KTL-
ZHM5
Rated output
power
15000 W 17000 W 20000 W 25000 W
Maximum
apparent power
16500 VA 18700 VA 22000 VA 27500 VA
Maximum active
power (cosφ = 1)
16500 W 18700 W 22000 W 27500 W
Rated output
voltage
220 V/380 V, 3W/N+PE
230 V/400 V, 3W/N+PE
239.6 V/415 V, 3W/N+PE
Maximum output
voltage at long-
term operation
See standards about the local power grid.
Rated output
current
22.8 A/380 V
21.7 A/400 V
20.9 A/415 V
25.8 A/380 V
24.5 A/400 V
23.7 A/415 V
30.4 A/380 V
28.9 A/400 V
27.8 A/415 V
38.0 A/380 V
36.1 A/400 V
34.8 A/415 V
Maximum output
current
25.2 A/380 V
23.9 A/400 V
23.1 A/415 V
28.6 A/380 V
27.1 A/400 V
26.1 A/415 V
33.6 A/380 V
31.9 A/400 V
30.8 A/415 V
42.0 A/380 V
39.9 A/400 V
38.5 A/415 V
SUN2000-(12KTL-25KTL)-M5 Series
User Manual 10 Technical Specications
Issue 03 (2023-02-15) Copyright © Huawei Digital Power Technologies Co., Ltd. 80

Huawei SUN2000 M5 Series Specifications

General

Max Efficiency	98.6%
Max Input Voltage	1100 V
MPPT Operating Voltage Range	200 V - 1000 V
Operating Temperature Range	-25°C to +60°C
Communication	RS485, 4G (optional)
