Huawei SUN2000 M5 Series User Manual

Item SUN2000-15KTL-
ZHM5
SUN2000-17KTL-
ZHM5
SUN2000-20KTL-
ZHM5
SUN2000-25KTL-
ZHM5
Output voltage
frequency
50 Hz/60 Hz
Power factor 0.8 leading... 0.8 lagging
Output DC
component DCI
< 0.25% of the rated output
Maximum total
harmonic
distortion AC
THDI
< 3% under rated conditions. Single-order harmonic meets the VDE4105
requirements.
Protection
Item SUN2000-15KTL-
ZHM5
SUN2000-17KTL-
ZHM5
SUN2000-20KTL-
ZHM5
SUN2000-25KTL-
ZHM5
Overvoltage
category
PV II/AC III
Input DC switch Supported
Anti-islanding
protection
Supported
Output
overcurrent
protection
Supported
Input reverse
connection
protection
Supported
DC surge
protection
TYPE II
AC surge
protection
CLASS II
Insulation
resistance
detection
Supported
Residual current
monitoring unit
(RCMU)
Supported
SUN2000-(12KTL-25KTL)-M5 Series
User Manual 10 Technical Specications
Issue 03 (2023-02-15) Copyright © Huawei Digital Power Technologies Co., Ltd. 81

Huawei SUN2000 M5 Series Specifications

General

Max Efficiency	98.6%
Max Input Voltage	1100 V
MPPT Operating Voltage Range	200 V - 1000 V
Operating Temperature Range	-25°C to +60°C
Communication	RS485, 4G (optional)
