Huawei SUN2000 M5 Series User Manual

Item SUN2000-12K
TL-M5
SUN2000-15K
TL-M5
SUN2000-17K
TL-M5
SUN2000-20K
TL-M5
SUN2000-25K
TL-M5
Maximum
input current
per MPPT
20 A (one PV string)/30 A (one MPPT)
Maximum
short-circuit
current per
MPPT
40 A
Minimum
startup
voltage
200 V
MPPT voltage
range
200–1000 V
Full-load
MPPT voltage
range
370–800 V 410–800 V 440–800 V 480–800 V 530–800 V
Rated input
voltage
600 V
Maximum
number of
inputs
4
Number of
MPPTs
2
Note a: The maximum input voltage is the maximum DC input voltage that the inverter can
withstand. If the input voltage exceeds this value, the inverter may be damaged.
Output
Item
SUN2000-12K
TL-M5
SUN2000-15K
TL-M5
SUN2000-17K
TL-M5
SUN2000-20K
TL-M5
SUN2000-25K
TL-M5
Rated output
power
12000 W 15000 W 17000 W 20000 W 25000 W
Maximum
apparent
power
13200 VA 16500 VA 18700 VA 22000 VA 27500 VA
Maximum
active power
(cosφ = 1)
13200 W 16500 W 18700 W 22000 W 27500 W
SUN2000-(12KTL-25KTL)-M5 Series
User Manual 10 Technical Specications
Issue 03 (2023-02-15) Copyright © Huawei Digital Power Technologies Co., Ltd. 87

Huawei SUN2000 M5 Series Specifications

General

Max Efficiency	98.6%
Max Input Voltage	1100 V
MPPT Operating Voltage Range	200 V - 1000 V
Operating Temperature Range	-25°C to +60°C
Communication	RS485, 4G (optional)
