Huawei SUN2000 M5 Series User Manual

Item SUN2000-12K
TL-M5
SUN2000-15K
TL-M5
SUN2000-17K
TL-M5
SUN2000-20K
TL-M5
SUN2000-25K
TL-M5
Rated output
voltage
220 V/380 V, 3W/N+PE
230 V/400 V, 3W/N+PE
239.6 V/415 V, 3W/N+PE
Maximum
output
voltage at
long-term
operation
See standards about the local power grid.
Rated output
current
18.2 A/380 V
17.3 A/400 V
16.7 A/415 V
22.8 A/380 V
21.7 A/400 V
20.9 A/415 V
25.8 A/380 V
24.5 A/400 V
23.7 A/415 V
30.4 A/380 V
28.9 A/400 V
27.8 A/415 V
38.0 A/380 V
36.1 A/400 V
34.8 A/415 V
Maximum
output current
20.2 A/380 V
19.1 A/400 V
18.5 A/415 V
25.2 A/380 V
23.9 A/400 V
23.1 A/415 V
28.6 A/380 V
27.1 A/400 V
26.1 A/415 V
33.6 A/380 V
31.9 A/400 V
30.8 A/415 V
42.0 A/380 V
39.9 A/400 V
38.5 A/415 V
Output
voltage
frequency
50 Hz/60 Hz
Power factor 0.8 leading ... 0.8 lagging
Output DC
component
DCI
< 0.25% of the rated output
Maximum
total
harmonic
distortion AC
THDI
< 3% under rated conditions. Single-order harmonic meets the VDE4105
requirements.
Protection
Item
SUN2000-12K
TL-M5
SUN2000-15K
TL-M5
SUN2000-17K
TL-M5
SUN2000-20K
TL-M5
SUN2000-25K
TL-M5
Overvoltage
category
PV II/AC III
Input DC
switch
Supported
Anti-islanding
protection
Supported
SUN2000-(12KTL-25KTL)-M5 Series
User Manual 10 Technical Specications
Issue 03 (2023-02-15) Copyright © Huawei Digital Power Technologies Co., Ltd. 88

Huawei SUN2000 M5 Series Specifications

General

Max Efficiency	98.6%
Max Input Voltage	1100 V
MPPT Operating Voltage Range	200 V - 1000 V
Operating Temperature Range	-25°C to +60°C
Communication	RS485, 4G (optional)
