Huawei SUN2000 Series User Manual

7 Man-Machine Interactions
7.1 Operations with the SUN2000 App
7.1.1 App Introduction
Functions
● The FusionSolar app is recommended when the SUN2000 is connected to the
FusionSolar hosting cloud. The SUN2000 app is recommended when the
SUN2000 is connected to other management systems.
● The SUN2000 or FusionSolar app (app for short) is a mobile phone app that
communicates with the SUN2000 over a WLAN/Bluetooth module or a USB
data cable to allow for querying alarms, setting parameters, and performing
routine maintenance as an easy-to-use maintenance platform.
Connection Mode
After the DC or AC side of the SUN2000 is powered on, you can connect the app
to it through a WLAN module, a Bluetooth module or a USB data cable.
NO TICE
● Over a WLAN module: The USB-Adapter2000-C WLAN module is supported.
● Over a Bluetooth module: The USB-Adapter2000-B Bluetooth module is
supported.
● Over a USB data cable: The USB 2.0 port is supported. Use the USB data cable
delivered with the mobile phone.
● Mobile phone operating system: Android 4.0 or later.
● Recommended phone brands: Huawei and Samsung.
SUN2000-(100KTL, 110KTL, 115KTL)-M2
User Manual 7 Man-Machine Interactions
Issue 02 (2022-06-30) Copyright © Huawei Technologies Co., Ltd. 63

Huawei SUN2000 Series Specifications

General

Max Efficiency	98.6%
MPPT Efficiency	99.9%
Protection Rating	IP65
Max. DC Voltage	1100 V
Rated AC Frequency	50 Hz / 60 Hz
Rated Power	3kW - 10kW
Operating Temperature Range	-25 °C ~ +60 °C
Communication	RS485
Rated AC Power	3kW - 10kW
Power Factor Adjustment Range	0.8 leading to 0.8 lagging
Total Harmonic Distortion (THD)	≤ 3%
Protection	DC reverse polarity
Cooling	Natural convection
DC Connection	MC4
