Figure 7-6 Login
7.1.4 Setting Parameters
7.1.4.1 Setting Grid Parameters
Choose Settings > Grid parameters to set grid parameters.
No.
Parameter Description
1 Grid Code Set this parameter based on the grid code of the country or
region where the inverter is used and the inverter application
scenario.
2 Isolation Set the working mode of the inverter based on the grounding
status at DC side and the connection to the power grid.
3 Output mode Species whether the inverter output has a neutral wire based
on the application scenario.
4 Auto start upon grid
recovery
Species whether to allow the inverter to automatically start
after the power grid recovers.
5 Grid connection delay
after grid recovery (s)
Species the time after which the inverter begins restarting
after the power grid recovers.
SUN2000-(100KTL, 110KTL, 115KTL)-M2
User Manual 7 Man-Machine Interactions
Issue 02 (2022-06-30) Copyright © Huawei Technologies Co., Ltd. 70
