7 Trolling Motor Mount
Connecting the Shaft Mount to the Landscape Mode Mount
The ratchets are keyed.
4. Secure the shaft mount to the Landscape Mode mount with one of the included
lock washers and 1/4-28 screws, using the provided hex bit. Hand tighten the
screw until the lock washer is fully compressed (see the illustration Compressing
the Lock Washer), and then tighten an additional 1/4 turn. Hand tighten only!
