21 Choke Cable Installation
4. Strip back the shield on each end of the cut wires approximately 1/4 inch
(6.4 mm).
5. Connect the stripped wires of the charger cable to the choke using the butt
connectors on both sides of the cut wire (red to white and black to black).
6. Securely crimp the wires in the butt connectors.
7. Apply heat over the splice connection shrink insulation to secure the connection.
CAUTION
Use extreme caution when applying heat to the shrink insulation.
8. Connect the terminals on the charger cable to the cranking battery.
