Removing the Shade (If Necessary)
■ Lower the shade completely.
■ Remove the two screws securing the top cord guide
inplace.
Standard Installation Brackets
■ While holding the rail, loosen the tab screw on each
bracket to release the rail.
NOTE: For a wide shade, there may be a center
installation bracket.
Optional Swivel Brackets
■ While holding the bottom rail, pull the locking tab to rotate the
swivel arm to the open position to release the bottom rail.
End Mount Brackets.
■ Reverse the installation procedures. See “Mount Installation
Brackets — End Mount” on page 5.
Screws
Top Cord
Guide
Shade Lift
Cords
Locking
Tab
Screw Holes
CARE
13
