Hunter Douglas Duette EasyView Arch User Manual

Installation Overview
■ Your order will include two installation brackets specific to the fabric pleat size and type of
brackets ordered.
■ If the arch is over 30" wide, your order
will also include a center bracket.
Mounting Types and Window Terminology
If the installation brackets are mounted correctly, the rest of the installation process follows very
easily. The Duette
®
EasyView
®
Arch can be inside mounted or end mounted.
■ Refer to the appropriate page below based on your order:
➤ Inside Mount — Page 4
➤ End Mount — Page 5
3
/ 4 "
Standard
Installation
Bracket
3
/ 8 "
Standard
Installation
Bracket
3
/ 4 "
Swivel
Bracket
(Optional)
3
/ 8 "
Swivel
Bracket
(Optional)
3
/ 8 "
End Mount
Bracket
3
/ 4 "
End Mount
Bracket
3
/ 8 " and
3
/ 4 "
Center Bracket
Molding
Sill
JambJamb
Inside Mount
Shade fits within
window opening.
End Mount
Shade fits within top
of window opening.
INSTALLATION
3

Hunter Douglas Duette EasyView Arch Specifications

General

Brand	Hunter Douglas
Model	Duette EasyView Arch
Category	Indoor Furnishing
Language	English
