INSTALLATION
4
■
Measure and mark the middle groove on each mounting
channel starting at 2" from each end and make additional
marks located approximately 18" apart.
■
Drill the screw holes in the mounting channels using a
5
⁄
32
" drill bit.
■
Test fit the left mounting channel into the window
opening.
➤
If the gap is greater than
1
⁄
16
", select the proper
combination of top and bottom end caps to minimize
the gap.
NOTE: D-seal on the top of the top end caps can be effective in reducing light gaps.
➤
Attach the end caps as shown and test fit to ensure a snug fit.
■
Repeat for the right side.
Gap
Top Left Bottom Left
