11
System and Controller Wiring
Pro-C or PCC with Wired Solar Sync
Compatible system: SOLAR-SYNC-SEN
The Pro-C or PCC controller has Solar Sync control built
in, allowing the sensor to be wired directly to the sensor
terminals inside the controller. Mount the sensor using the
included hardware.
Pro-C or PCC with Wireless Solar Sync
Compatible system: WSS-SEN
The Pro-C or PCC controller has Solar Sync control built
in, allowing the receiver to be wired directly to the sensor
terminals inside the controller. Mount the receiver in the
knockouts provided on the side of the controller or mount
the receiver and sensor to the wall with the wall mounting
bracket and hardware provided.
Pro-C Pro-C
