Hunter XC Hybrid Programming Guide

XC HYBRID
WATERING SCHEDULE
?
LIT-511 XCH-SS 5/20
PROGRAM A PROGRAM B PROGRAM C
DAYS OF THE WEEK
M T W T F S S M T W T F S S M T W T F S S
INTERVAL OR ODD/EVEN
NON-WATER DAYS
PROGRAM START TIMES
1
2
3
4
A program is a watering schedule that includes a start time(s), run time(s), and water day(s).
A start time is the time of day the stations in the program start watering.
A run time is the watering length per station (zone).
One start time is needed to run the entire program.
STATION LOCATION STATION RUN TIME STATION RUN TIME STATION RUN TIME
1
2
3
4
5
6
7
8
9
10
11
12
© 2020 Hunter Industries Inc. Hunter and the Hunter logo are trademarks of
Hunter Industries, registered in the U.S. and other countries.
https://hunter.direct/XCHhelp

Hunter XC Hybrid Specifications

General

Voltage	24 VAC
Display	LCD
Start Times per Program	4 start times per program
Enclosure	Weather-resistant
Cycle and Soak	Yes
Manual Watering	Yes
Zones	Up to 8
Battery Backup	Yes
Weather Adjustment	Yes
