HURST eDRAULIC SP 333 E2 - 4.3 Hydraulic Circuit and Controls; 5. Operation; 5.1 Power Source Connection

13
4.4 Operating movement controls
Thepistonmovementiscontrolledbythestargripontheattachedvalve(seeillustrationbelow).
Stargrip
5.1 Battery or power supply for eDRAULIC device
5. Operation
Commissioning
Beforeinitialoperation,thebattery(whereused)oftherescuedevicemustbefullyloaded,
usingtheexternalcharger.
4.3 Hydraulic circuit diagram
Toenablecomprehensionofthefunction,asimpliedhydraulicramoftherescueequipment
(A)+handvalve(B)aredepictedhere.
A
B
pulling/squeezing
spreading
