HURST eDRAULIC SP 333 E2 - 11.2 Peeling, Noise, and Temperature Data; 11.5 Oscillation and Vibration

37
11.3 Noise emission (based on standard EN ISO 3744)
Device type
SP 333 E2, SP 555 E2,
SP 777 E2
Battery type used for device Lithium/ion
Idling
(measuredatadistanceof1m,
accordingtoEN)
[dB(A)] 74
Full load
(measuredatadistanceof1m,
accordingtoEN)
[dB(A)] 77
Idling
(measuredatadistanceof4m,
accordingtoNFPA)
[dB(A)] 69
Full load
(measuredatadistanceof4m,
accordingtoNFPA)
[dB(A)] 71
11.4 Operating and storage temperature ranges
Operating temperature [°C]/[°F] -20 … +55 -4 … +131
Storage temperature
(devicenotinoperation)
[°C]/[°F] -30 … +60 -22 … +140
11.5 Oscillation / vibration
Thetotaloscillationvalue/vibrationvaluetowhichtheupperlimbsareexposed,isusually
below2.5m/s².
Highervaluesmaybemeasuredforshortperiodsasaresultofinteractionwiththematerials
tobeprocessed.
(Theoscillations/vibrationsweredeterminedinaccordancewithDINENISO20643.)
11.2 Peeling
Device type SP 333 E2 SP 555 E2 SP 777 E2
Max. sheet
steel thickness “t”
[mm] 2 3 4
[in.] 0.08 0.12 0.16
Max. possible opening
[mm] 510 640 725
[in.] 20.1 25.2 28.5
