9.2.2 Function and load test
Ifthereisanydoubtregardingthesafetyorreliabilityofadevice,afunctionandstresstest
mustalsobeperformed.
HURSTo󰀨ersappropriatetestequipmentforthis.
9.3 Repairs
9.3.1 Replacing the plug-on tips
Procedure:
1. Inordertoremovetheplug-ontips“G”,youneedtopushthebuttons“J”onbothsidesof
aspreaderarmcompletelyandsimultaneouslyandthenremovetheplug-ontipfromthe
spreaderarmbypullingitforwards.
2. Placethenewtipsontothearmuntiltheyautomaticallyclickinplaceonthespreaderarm.
H
G
J
NOTE:
Alwaysreplacebothplug-ontips.
Wheninsertingthenewtips,pushbothbuttons“J”untilthetipcanbeslidover
them.
Aftertting,makesurethatbothbuttons“J”arelockedoneacharm(thatthey
arebackintheiroriginalposition).
H
J
G
