HURST eDRAULIC SP 333 E2 - Page 36

36
Device type SP 777 E2
Item number 271777000
Dimensions (excluding battery)
LxWxH
[mm] 1075x308x285
[in.] 42.3 x 12.1 x 11.2
Minimum spreading force
(atadistanceof25mm/
0.98inchesfromthetips)
[kN] 63
[lbf.] 14160
Max. possible spreading
force *
[kN] 600
[lbf.] 134900
LSF spreading force
(accordingtoNFPA)
[kN] 59
[lbf.] 13260
HSF spreading force
(accordingtoNFPA)
[kN] 85
[lbf.] 19110
Maximum spreading path
[mm] 813
[in.] 32.0
Maximum pulling force
(withapprobiatechainset)
[kN] 60
[lbf.] 13490
Pulling path
(withapprobiatechainset)
[mm] 655
[in.] 25.8
HPF pulling force
(according
toNFPA)
[kN] 49
[lbf.] 11016
LPF pulling force
(according
toNFPA)
[kN] 30
[lbf.] 6744
Mass (excl. battery)
[kg] 24,5
[lbs.] 54.0
Nominal electrical voltage
(withpowersupply)
[V] 25
Nominal electrical voltage
(withlithium-ionbattery)
[V] 25,2
Protection category
IP54
*Computedvalue
