7 DASH
56
Info
Before the first service, the tachometer always flashes
with a slow frequency (5 Hz) when the engine speed
reaches 6500 rpm.
The tachometer flashes with a slow frequency (5 Hz)
in the following cases: The coolant temperature is
lower than 35 °C and the engine speed has reached
6500 rpm, or the recommended shift speed of
8000 rpm has been reached.
The tachometer flashes with a fast frequency (10 Hz)
when the maximum engine speed is reached.
7.17 Odometer
S04379-01
– Press the + or ‑ button repeatedly until ODO is shown on the
combination instrument.
ODO shows the motorcycle’s overall mileage.
