Installation (cont’d)
Joiningpart3
Joiningpart4
1) Remove deck pans adjacenttothe casesjoining line.
2) Remove rear modular DSCH adjacenttothe casesjoining line
3) Installjoining part 1and 2(seepartlist) usingsilicone adhesive andpushbackall theway.
4) Installtop joiningpartusing silicone adhesive (see part list)and push allthe wayforward.
5) Usingdoubleside3M® adhesive tape installjoining parts3and4(see part list)
andensurealigned symmetricallyonthe topofthe casesjoining line.
6) Reinstalldeckpansand modularDSCHs.
Q3 MV-BC JOININGCASETOCASE-STEP 3
D
DETAIL D
Joining
part 1
Joining
part 2
To Next Page
