Huvitz CLM-3100P Service Manual

16
AUTO-LENSMETER
2.6. Diopter Setting Variables List
The followings are diopter setting variables list:
If diopter controlling is performed normally, the length of each row (L) decreases row by row.
DISP SCREEN INFORMATION
CEN : (+3.03.0446, +209.79) : center of the four points in 0D state.
0th: L=194.24; 1.00, 1.00, 1.00, 1.00 : average distance and distance rates
between the four points and -25D -25D
1th: L=183.25; 1.00, 1.00, 1.00, 1.00 : average distance and distance rates
between the four points and -20D
…
5th: L=136.88; 1.00, 1.00, 1.00, 1.00 : average distance and distance rates
between the four points and -2.5D
6th: L=130.63; 1.00, 1.00, 1.00, 1.00 : average distance and distance rates
between the four points and 0D
7th: L=121.87; 1.00, 1.00, 1.00, 1.00 : average distance and distance rates
between the four points and +2.5D
…
11th: L=+46.25; 1.04, 0.98, 1.00, 0.98 : average distance and distance rates
between the four points and +20D
12th: L=+22.25; 1.04, 0.98, 1.00, 0.98 : average distance and distance rates
between the four points and +25D
