Huvitz CLM-3100P Service Manual

32
AUTO-LENSMETER
No
Component Removal method
1 UV cover(Lower)
2 UV bone
3 UV led
4 UV teflon(Upper)
5 UV rec
6 UV teflon(Lower)
7
8
- Separate the 'UV cover(Lower) 1' from the
'Frame support(UV)' through removing four M3X5L screws.
And then separate the 'UV LED 3', 'UV teflon 4',
'UV rec 5' and 'UV teflon(Lower) 6'.
- Be careful not to bend the rec's pin when
you separate the 'UV rec'.
- Assembly is the reverse procedure of disassembly.
