36
AUTO-LENSMETER
No
Component Removal method
1 Shaft guide
2 Shaft holder
3 Shaft nut
4 Band washer
5 Gear washer
6 Gear washer
7 Gear shaft
8 Gear
9
10
11
12
- Separate the 'Shaft guide 1' from 'Back bone' through
removing M3X8L screws.
- Remove the 'Shaft holder' by wrench for M3 Set screw.
- Separate the 'Gear nut 3', 'Band washer 4',
'Teflon washer 5', 'Teflon washer 6', 'Gear shaft 7'
and 'Gear 8'.
- Next, separate the 'Gear shaft 7', 'Gear 8' through
removing two M2X8L screws.
- In assembling, coincide the center of 'Gear 8' and the
center of teetch of 'PD shaft'.
- Assembly is the reverse procedure of disassembly.
