AUTO-LENSMETER
No
Component Removal method
1 Lens housing bone
2 CCD lens
3 Lens housing bone retainer
4 LED housing
5 LED
6 Pin hole(Upper)
7 Teflon scatter
8 Ball lens
9
10
- Separate the 'Lens housing bone' and 'Back bone'
through removing 4 M3X8L screws.
- Remove the 'Lens housing bone retainer 3', the
'CCD lens 2'.
- Separate the 'LED housing' and 'Lens housing bone'
through removing three M3X8L Set screws.
- Remove the 'Pin hole(Upper) 6', 'Teflon 7' and
'Ball lens' in sequence at the front of 'Lens housing'.
- Assembly is the reverse procedure of disassembly.
