SECTION 1

Temperature compensated transducer RYT15 & RWT15 - is connected: -

Shield to terminal 6

Blue to terminal 7

Black to terminal 8

Analogue Output

Analogue - is connected : - Shield to terminal 11

Positive +ve to terminal 12

Negative -ve to terminal 13

RS485 Output

RS485 - is connected : - Shield to terminal 3

Negative –ve to terminal 4

Positive +ve to terminal 5

Note: - See Page 8 for transducer extension cables.

Ref: MINIFLEX LR MANUAL Rev. 0 4
