3.4 Technical Data HV04-HV07
Model Number HV04 HV05 HV07 HV07RS
PERFORMANCE
F.A.D. litres/sec (cfm) @ 7 bar 11 (24) 15 (32) 21 (44)
F.A.D. litres/sec (cfm) @ 10 bar 9 (20) 12 (25) 17 (35)
F.A.D. litres/sec (cfm) @ 6 bar 0-22 (0-46)
Noise Level - dBA 66 66 67
Power - kW (hp) 4 (5.5) 5.5 (7.5) 7.5 (10)
Starter Type Automatic DOL & SD Inverter Soft Start
Drive Type Direct
Operating Controls Continuous Run, Automatic Stop/Start,
Reduced Energy Vent System
Variable
Rotation Speed - rev/min 50Hz (60 Hz) 1450 (1760) 990-2130
Ambient Temperature Range °C 0 to 45 0 to 40
Maximum Relative Humidity % 85 non-condensing
Air Discharge Temp - °C (above ambient) <6 <8 <10
FACTORY SETTINGS
Nominal Pressure - bar 7.0 or 10.0 7.0
Minimum Pressure Valve - bar 5.5 to 6.0
Load Pressure - bar (PL) 6.5 or 9.5 7.0
Unload Pressure - bar (PU) 7.5 or 10.5 7.5
Servo Valve - bar 8.0 or 11.0 8.0
Run-on Time after PU - secs (RT) 120 60
Run-on-Time to Stop - secs (ST) 2
Pressure Display Units (P>) 0 (bar) (1 = psi, 2 = kpa)
Temperature Display Units (T>) 0 = °C (1 = °F)
Vacuum Relief Valve 1.5 turns anti-clockwise
INSTALLATION
ACE Dimensions D x W x H -mm 635 x 500 x 1050
Air Outlet Size - Rp 3/4
Minimum Room Volume - m
3
15
Air Inlet/Outlet Area - m
2
0.3
Ventilation Rate - m
3
/h
2000
Cooling Air Flow m
3
/h (cfm)
1850 (1089)
Recommended Air Receiver Capacity - L 250
COMPRESSOR OIL
Approved compressor oil Fluid Force Red 2000 (Mineral) & HPO (Synthetic)
Oil Capacity - litres 3
ELECTRICAL
Starter reference 400V 50Hz DOL 35121
Circuit diagram 400V 50Hz DOL 77319
Starter reference 400V 50Hz SD 35120
Circuit diagram 400V 50Hz SD 77318
Starter reference 400/460V 50/60Hz RS 35124
Circuit diagram 400/460V 50/60Hz RS 77117
Starter reference 200-575V 60Hz DOL 3PH 35122
Circuit diagram 200-575V 60Hz DOL 3PH 77320
Starter reference 230V 60Hz DOL 1PH 35123
Circuit diagram 230V 60Hz DOL 1PH 77321
