Product Information 3
8 ST16135-00E
3.6 Technical Data HV30-HV45
Model Number HV30 HV37 HV45 HV30RS HV37RS HV45RS
PERFORMANCE
F.A.D. litres/sec (cfm) @ 8 bar 86 (182) 99 (210) 122 (259)
F.A.D. litres/sec (cfm) @ 10 bar 76 (162) 88 (187) 109 (231)
F.A.D. litres/sec (cfm) @ 6 bar 0-93
(0-197)
0-108
(0-228)
0-132
(0-280)
Noise Level - dBA 73 73 73 73
Power - kW (hp) 30 (40) 37 (50) 45 (60) 30 (40) 37 (50) 45 (60)
Starter Type Automatic DOL & Star/Delta Inverter Soft Start
Drive Type Direct
Operating Controls Continuous Run, Automatic Stop/Start,
Reduced Energy Vent System
Variable
Rotation Speed - rev/min 50Hz (60 Hz) 1450 (1760) 0-1800 0-1900 0-1900
Ambient Temperature Range °C 0 to 45 0 to 40
Maximum Relative Humidity % 85 non-condensating
Air Discharge Temp - °C (above ambient) <10
FACTORY SETTINGS
Nominal Pressure - bar 8.0 or 10.0 8.0
Minimum Pressure Valve - bar 5.5 to 6.0
Load Pressure - bar (PL) 7.5 or 9.5 8.0
Unload Pressure - bar (PU) 8.5 or 10.5 8.5
Servo Valve - bar 9.0 or 11.0 9.0
Run-on-Time after PU - secs (RT) 60 (8 bar) 90 (10bar) 60
Run-on-Time to Stop - secs (ST) 2
Pressure Display Units (P>) 0 (bar) (1 = psi, 2 = kpa)
Temperature Display Units (T>) 0 = °C (1 = °F)
Vacuum Relief Valve 1.5 turns anti-clockwise
INSTALLATION
ACE Dimensions D x W x H - mm 1100 x 900 x 1592
Air Outlet Size - Rp 1-1/2 1-1/2
Minimum Room Volume - m
3
60 90 60 90
Air Inlet/Outlet Area - m
2
0.6 1.0 0.6 1.0
Ventilation Rate - m
3
/h
8,300 10,200 11,000 8,300 10,200 11,000
Cooling Air Flow m
3
/h (cfm)
5020
(2955)
6320
(3720)
6550
(3855)
5020
(2955)
6320
(3720)
6550
(3855)
Recommended Air Receiver Capacity - L 500 900 500 900
COMPRESSOR OIL
Approved compressor oil Fluid Force Red 2000 (Mineral) & HPO (Synthetic)
Oil Capacity - litres 23.0
ELECTRICAL
Starter reference 400V 50Hz SD 35135 35133
Circuit diagram 400V 50Hz SD 77400 77400
Starter reference 200V 60Hz DOL 35136 35134
Circuit diagram 200V 60Hz DOL 77401 77401
Starter reference 200-575V 60Hz DOL 35161
Circuit diagram 200-575V 60Hz DOL 77428
Starter reference 400/460V 50/60Hz RS 35126 35127 35128
Circuit diagram 400/460V 50/60Hz RS 77399 77399 77399
