MAINTENANCE
1
powermax1000 Service Manual 3-13
Control board (PCB3)
Board common (TP1) PFC IGBT (Q7)
Flyback circuit
T
orch (J18)
Gas manifold Inverter circuit
Power switch (S1)
Input diode
Power factor circuit
Inverter IGBT (Q6)
Output diodes
Pilot arc IGBT (Q8)
Work lead
