2-6 powermax1000 Operator Manual
Symbols and Markings
S MARK
The S mark indicates that the power supply and torch are suitable for use in environments with
increased hazard of electrical shock. The hand torches must
have shielded consumable parts to maintain
S mark compliance.
IEC Symbols Used
The following symbols may appear on the power supply data plate, control labels and switches.
O
l
Direct Current (DC)
The terminal for the external
protective (earth) conductor
AC input power
connection
Plasma torch cutting and
gouging
Alternating current (AC)
An inverter-based power
source
Volt/amp curve, "drooping"
characteristic
Power is off
Power is on
Plasma torch in the TEST
position (cooling and cutting
gas exiting nozzle)
