Hypertherm powermax1250 Service Manual

SPECIFICATIONS
4
2-4 powermax1250 Service Manual
Handheld cutting capacity at 80 amps
Recommended capacity 7/8 inch (22 mm)
Maximum capacity 1-1/8 inch (29 mm)
Severance capacity 1-1/2 inch (38 mm)
Mechanized cutting capacity at 80 amps
Recommended capacity 3/8 inch (10 mm)
Maximum capacity 5/8 inch (16 mm)
Gouging capability
12.2 pounds (5.5 kg) hour
(metal removal rate on mild steel)
Weight
7.2 pounds (3.3 kg) with 25 ft (7.5 m) lead
T80 13.9 pounds (6.3 kg) with 50 ft (15 m) lead
20.6 pounds (9.4 kg) with 75 ft (22.5 m) lead
4.5 pounds (2.0 kg) with 15 ft (4.5 m) lead
8.3 pounds (3.8 kg) with 25 ft (7.5 m) lead
T80M 9.9 pounds (4.5 kg) with 35 ft (10.7 m) lead
15.0 pounds (6.8 kg) with 50 ft (15 m) lead
21.7 pounds (9.9 kg) with 75 ft (22.5 m) lead
T80 torches
