Hypertherm powermax1250 - Torch Replacement

MAINTENANCE
powermax1250 Service Manual 3-35
4
Torch replacement
Turn OFF (O) the power switch.
Unplug the power cord from the power receptacle.
Open the Easy Torch Removal (ETR) door and route the lead through the end cap.
OFF
ON
ETR
Door
End Cap
1
2
3
