MAINTENANCE
powermax1250 Service Manual 3-13
3
Control board (PCB3)
Board common (TP1)
PFC IGBT (Q7) Flyback circuit
Torch (J18) Gas manifold Inverter circuit
Power switch (S1)
Input diode
Power factor circuit
Inverter IGBT (Q6)
Output diodes
IGBT, Pilot Arc (Q8)
Work lead
