6-11

powermax600 Service Manual

PARTS LIST - TORCH AND CONSUMABLES

RECOMMENDED SPARE PARTS - PAC123 TORCH

Part

Number Description

001288 ........ Handle, 2 Sides

020620 ........ Sleeve, Machine Torch Position

075339 ........ Screws, P/S, # 4 X 1/2, PH, RND, S/B

086001 ........ PAC123T Hand Torch Assembly with 15 ft / 4.5 m Lead (No Quick Disconnect)

086002 ........ PAC123T Hand Torch Assembly with 25 ft / 7.5 m Lead (No Quick Disconnect)

086003 ........ PAC123T Hand Torch Assembly with 50 ft / 15 m Lead (No Quick Disconnect)

086004 ........ PAC123M Machine Torch Assembly with 15 ft / 4.5 m Lead (No Quick Disconnect)

086005 ........ PAC123M Machine Torch Assembly with 25 ft / 7.5 m Lead (No Quick Disconnect)

086006 ........ PAC123M Machine Torch Assembly with 50 ft / 15 m Lead (No Quick Disconnect)

086023 ........ PAC123T Hand Torch Assembly with 15 ft / 4.5 m Lead (with Quick Disconnect)

086024 ........ PAC123T Hand Torch Assembly with 25 ft / 7.5 m Lead (with Quick Disconnect)

086025 ........ PAC123T Hand Torch Assembly with 50 ft / 15 m Lead (with Quick Disconnect)

086026 ........ PAC123M Machine Torch Assembly with 15 ft / 4.5 m Lead (with Quick Disconnect)

086027 ........ PAC123M Machine Torch Assembly with 25 ft / 7.5 m Lead (with Quick Disconnect)

086029 ........ PAC123M Machine Torch Assembly with 50 ft / 15 m Lead (with Quick Disconnect)

120570 ........ Hand Torch Main Body with Safety Switch

120583 ........ Machine Torch Main Body with Safety Switch

128374 ........ Replacement Machine Torch Lead, 15 ft / 4.5 m (No Quick Disconnect)

128375 ........ Replacement Machine Torch Lead, 25 ft / 7.5 m (No Quick Disconnect)

128376 ........ Replacement Machine Torch Lead, 50 ft / 15 m (No Quick Disconnect)

128377 ........ Replacement Hand Torch Start Switch (switch and wire splices)

128572 ........ Replacement Machine Torch Lead, 15 ft / 4.5 m (with Quick Disconnect)

128573 ........ Replacement Machine Torch Lead, 25 ft / 7.5 m (with Quick Disconnect)

128574 ........ Replacement Machine Torch Lead, 50 ft / 15 m (with Quick Disconnect)

129475 ........ Replacement Hand Torch Lead, 15 ft / 4.5 m (No Quick Disconnect)

129476 ........ Replacement Hand Torch Lead, 25 ft / 7.5 m (No Quick Disconnect)

129477 ........ Replacement Hand Torch Lead, 50 ft / 15 m (No Quick Disconnect)

129599 ........ Replacement Hand Torch Lead, 15 ft / 4.5 m (with Quick Disconnect)

129600 ........ Replacement Hand Torch Lead, 25 ft / 7.5 m (with Quick Disconnect)

129601 ........ Replacement Hand Torch Lead, 50 ft / 15 m (with Quick Disconnect)

10-99

Hypertherm powermax600 Service Manual
