Service Manual
PARTS LIST - 208/240/480V
POWER SUPPLY - 208/240/480V
Bottom and Left Side
Index No. Part No. Description Ref. Desig. Quantity
1 014207 Xfmr:Powermax800/900 208-240-480 Control T1 1
2 014228 Xfmr:Powermax900 208-240-480 Power T2 (w/TS2) 1
3 014230 Inductor:Powermax900 0.8MH 55A L1 1
4 027080 Fan:225CFM 120VAC 50-60HZ M1 1
5 041532 PCB Assy:Powermax800/900-ZB Power 1
029978* Heatsink SA:Pwrmx800/900 PA Cont PCB Q3
6 004673* Heatsink:Powermax800/900 PA Cont
7 028908** Kit:Powermax800/900 Cooling Fan Filter
Notes: Bold part numbers and descriptions are subassemblies.
Indented normal type items are components of subassemblies
All mounting hardware in power supply drawings shown for reference only.
* Available only on power supplies with the pilot arc control option
** Available only as an option
See also Section 5 Parts List - 200/230/400V, and Section 6 Parts List - 400V CE
to identify parts for other Powermax900 power supplies.
