6-4

Service Manual

PARTS LIST - 400V CE

POWER SUPPLY - 400V CE

Top and Right Side

Index No. Part No. Description Ref. Desig. Quantity

1 003078 Relay:30A NO Mag Blwt QDisc Term CR2 1

129046 Heatsink SA:Powermax800/900 CE Power Unit 1

2 029998 IGBT Gate Drive SA:Powermax800/900 Q1 1

3 029998 IGBT Gate Drive SA:Powermax800/900 Q2 1

4 109018 Diode:600V 100A UFast Recovery Dual D2 1

5 109018 Diode:600V 100A UFast Recovery Dual D3 1

6 109043 Diode:1600V 30A 3PH Bridge Isol Bplr D1 1

7 041668 PCB Assy:Powermax900 Micro Control 1

8 041532 PCB Assy:Powermax800/900-ZB Power 1

9 014137 Current Sense Transformer, 40A CS1 1

10 014137 Current Sense Transformer, 40A CS2 1

11 008958 Fuse:1A 500V 10mmX38mm Slo F1, F2 2

12 008959 Fuse:20A 500V 10mmX38mm Slo 3

13 029978* Heatsink SA:Pwrmx800/900 PA Cont PCB Q3

14 041486* PCB Assy:Pwermax800/900 PA Cont

128286** Kit:Powermax900 Machine Interface 400V CE

15 041494** PCB Assy:Powermax800/900 Machine Interface

Notes: Bold part numbers and descriptions are subassemblies.

Indented normal type items are components of subassemblies.

All mounting hardware in power supply drawings shown for reference only.

* Available only on power supplies with the pilot arc control option

** Available only on power supplies with the machine interface option

See also Section 4 Parts List - 208/240/480V, and Section 5 Parts List -

200/230/400V to identify parts for other Powermax900 power supplies.

9-99
