Hypertherm powermax900 Service Manual

7-4
Service Manual
PARTS LIST - TORCH AND CONSUMABLES
Part Number Description (Quantity)
001285 ...................Box, Consumable Parts (1)
120573 ...................Electrode (3)
120574 ...................Electrode, Extended (1)
120577 ...................Nozzle, 55A, Shielded (3)
120578 ...................Nozzle, Pipe Saddle, Extended (1)
120607 ...................Nozzle, Gouging (1)
120601 ...................Shield, 55A (1)
120608 ...................Shield, Gouging (1)
120303 ...................Deflector (1)
044016 ...................O-Ring (3)
015152 ...................Nipple, 1/8 NPT,QDisc, Steel (1)
015604 ...................Reducer, 1/4 FPT X 1/8 NPT, Brass (1)
027055 ...................Lubricant, Silicone 1/4 Oz Tube (1)
Part Number Description (Quantity)
001285 ...................Box, Consumable Parts (1)
120573 ...................Electrode (3)
120574 ...................Electrode, Extended (3)
120577 ...................Nozzle, 55A, Shielded (3)
120606 ...................Nozzle, 35A, Extended (3)
120602 ...................Shield, PAC125M Machine Torch (1)
120303 ...................Deflector (1)
044016 ...................O-Ring (3)
015152 ...................Nipple, 1/8 NPT, QDisc, Steel (1)
015604 ...................Reducer, 1/4 FPT X 1/8 NPT, Brass (1)
027055 ...................Lubricant, Silicone 1/4 Oz Tube (1)
Machine Consumable Spare Parts Kit (128288)
Hand Consumable Spare Parts Kit (128287)
Consumable Spare Parts Kit - CE (128289)
Part Number Description (Quantity)
001285 ...................Box, Consumable Parts (1)
120573 ...................Electrode, Air (3)
120577 ...................Nozzle, 55A, Shielded (3)
120607 ...................Nozzle, Gouging (1)
120608 ...................Shield, Gouging (1)
120601 ...................Shield, 55A (1)
044016 ...................O-Ring (3)
015152 ...................Nipple, 1/8 NPT, QDisc, Steel (1)
015301 ...................Adapter, 1/8 NPT to 1/4 Hose (1)
027055 ...................Lubricant, Silicone 1/4 Oz Tube (1)
Consumable Parts Kits
