6-6

Service Manual

PARTS LIST - 400V CE

POWER SUPPLY - 400V CE

Bottom and Left Side

Index No. Part No. Description Ref. Desig. Quantity

1 014209 Xfmr:Powermax800/900 CE 400V Control T1 1

2 014229 Xfmr:Powermax800/900 200-230-400 Power T2 (w/TS2) 1

3 014230 Inductor:Powermax900 0.8MH 55A L1 1

4 027443 Fan:260CDM 120VAC 50-60HZ M1 1

5 041532 PCB Assy:Powermax800/900-ZB Power 1

029978* Heatsink SA:Pwrmx800/900 PA Cont PCB Q3

6 004673* Heatsink:Powermax800/900 PA Cont

7 028908** Kit:Powermax800 Cooling Fan Filter

8 129100 Capacitor SA:Powermax800/900-CE 1

Notes: Bold part numbers and descriptions are subassemblies.

Indented normal type items are components of subassemblies.

All mounting hardware in power supply drawings shown for reference only.

* Available only on power supplies with the pilot arc control option

** Available only as an option

See also Section 4 Parts List - 208/240/480V, and Section 5 Parts List -

200/230/400V to identify parts for other Powermax900 power supplies.
