HySecurity SlideDriver 50 VF Series Programming & Operation Manual

76 D0559 Rev. A SlideDriver/SlideDriver 50VF Series www.hysecurity.com
Type Alert/Fault/Error Display Buzzer Chirp Sequence Possible Cause & Suggested Corrective Action
ALERT ALERT 13
STIFF GATE
2 chirps per second every
15 seconds
The STC detects a gate that, over time, is requiring more power
to move it. Usually caused by degrading gate hardware or
debris in a slide gate track, this alert appears in the history log.
It does not affect opening or closing the gate.
• Check and correct gate hardware as required.
• Check motor brushes for excessive wear.
ALERT ALERT 14
STUCK GATE
2 chirps per second every
15 seconds
The STC detects that it cannot move the gate at all possible
caused by broken gate hardware or ice/snow buildup.
• Manually move the gate. Verify that it moves easily and is
unobstructed thoughout gate travel.
• Check and correct gate hardware, as required.
ALERT ALERT 17
BAD COIN BATTERY
2 chirps per second every
15 seconds
Replace the 3V coin battery that controls the internal clock, with
the AC power turned off. Use a CR2032 battery.
ALERT ALERT 18
CHANGE BATTERY
1 chirp a minute Batteries are not taking a charge properly. The STC has
detected that the 24VDC UPS batteries need to be replaced.
NOTE: The buzzer will chirp every minute until the UPS
batteries are replaced.
ALERT ALERT 19
FALSE SLOWDOWN
2 chirps per second every
15 seconds
Appears only on gate operators with VFD. Slowdown switch
tripped and released (less than 1 second) in middle of run.
Check for loose wires, limits and misaligned rails or limit ramps.
ALERT ALERT 20
EXT LOCK FAILED
2 chirps per second every
15 seconds
An interlock contact is closed, indicating that the M30 gate latch
(lock) is engaged, preventing the operator from starting. Check
the interlock and wiring.
ALERT ALERT 21
DRIVE TRIP
2 chirps per second every
15 seconds
M30/M50 gate travel will not occur until the alert is cleared. Any
open or close command resets the alert and starts the M30/
M50 gate moving, unless the VFD is experiencing a fatal error.
If you cannot clear the error alert by pressing the open or close
button, contact HySecurity.
ALERT ALERT 22
INTLOCK FAILURE
2 chirps per second every
3 seconds
Appears when the RS-485 communication connection is lost
for more than 5s between interlocked (dual gate) or sequenced
gate operators. Check cable connections and wiring. Make sure
both operators are working properly and have the same current
and up-to-date software versions. The alert auto clears when
communication between the two operators is restored. If the
operator on site is a singular gate and the display code ALERT
22 appears, access the Installer Menu. Verify the Installer Menu
items: DG (Dual gate) and SG (Sequential gate) are both set to
zero.
ALERT ALERT 24
EXT RELAY FAULT
2 chirps per second every
15 seconds
The Hy8Relay (extended relay module) is not being recognized.
Alert noted in diagnostic log.
Check the wiring:
• Make sure the slide switch on the side of the extended relay
module is set at “Normal.”
• (Y) Data + is connected to “A” DUAL GATE.
• (G) DATA - is connected to “B” DUAL GATE.
• Connector cable (4-pin) attaches to RS-485.
If the Hy8Relay module is not connected, access the Installer
Menu and check that the extended user relays are set to zero.
STC = R4 to RB (7-segment display)
SDC = R3 to R9 (16 character display)
STC = R4 to R11 (16 character display)
