User Menu Setting Options Menu Tasks & Explanations STC Wire
Connections
DA 0 (OFF)
DRIFT CLOS ALERT
0 = off (standard)
1 = on (detailed)
Set to 1, the operator sounds the 3-second “warn
before operate” buzzer alarm and initiates an open
command if the gate is forced, or drifts, off the open
limit switch. The motor starts to reopen the gate. The
motor runs for a maximum of 4s and, if the gate is not
fully open at the end of this period, the buzzer sounds
for 10s. The display shows ALERT 2 - DRIFT CLOSED.
N/A
PE 0 (OFF)
PHOTO EYE ALIGN
0 = off
1 = on
When set to 1, operator serves as an aide in photo-
eye emitter/receiver alignment. Buzzer chirps once
when emitter and receiver are not aligned. When
emitter and receiver are aligned, buzzer chirps twice.
If they go out of alignment again, buzzer will chirp
once. Alignment Mode is reset with a limit input or
reset input.
Sensor 1, 2 or 3
Sensor COM
CL 0
SET CLOCK
0 = off
1 = on
To set or adjust minute, hour, day, month or year,
select 1. Once clock is set, display automatically
returns to 0 setting. Signicant gate events are
logged and stamped with time and date. This feature
is useful to read historical operation data, which can
be accessed with a computer via USB or RS232 port
or the LG setting in User Menu.
N/A
LD 5
LCD CONTRAST
5
0 through 9
Under some extreme high or low temperature
conditions, it may be necessary to adjust LCD
contrast. Display is adjustable from 0-9 with
a factory default setting of 5. Not available with OLED
display
N/A
LG 0 (OFF)
VIEW EVENT LOG
0 = off
1 = on
With v5.53 (or later) software, you can set LG to 1 and
view abbreviated event logs on the display. These
messages are helpful for diagnostic purposes and
reviewing the gate operator’s event history. Over 300
events can be logged before the software begins
overwriting the existing history.
N/A
DS 0 (OFF)
DIAGNOSTIC LOGS
0 = off (standard)
1 = on (detailed)
Set this item to 1 to record all gate operator open
and close events, in addition to normal alert, fault
and error logs. This parameter automatically resets to
the default 0 (off ) after 24 hours, which is useful
when experiencing intermittent problems. Set to 0,
DC Controller logs pertinent gate operator events
such as faults, errors, or menu manipulation.
To read the log le, an
RS-232 cable and
PC laptop loaded
with HySecurity free
S.T.A.R.T. software is
required. Visit
www.hysecurity.com
To Next Page
