Table 1. Maintenance Schedule (Continued)
Item
No.
Item 8 hr/
Daily
500 hr/
3 mo
2000 hr/
1 yr
4000 hr/
2 yr
Procedure or
Quantity
Specification
19 Drive Axle Unit
Assembly
Gear Oil
X Check oil level.
2.6 liter (2.7 qt)
per chamber.
Use gear oil.
John Deere JDM
J20C
3 Tilt Cylinder Rod End
Pins
X L Use multipurpose
grease.
See NOTE 1.
12 Brake Pedal Linkage
and Shafts
L Lubricate
linkage and
shafts.
See NOTE 2.
Use multipurpose
grease.
See NOTE 1 and
NOTE 11.
18 Lift Chains L Check stretch
and lubricate.
See NOTE 2 and
NOTE 3.
30W Engine Oil
18 Lift Chains X X Check
adjustment and
length.
See NOTE 2.
15 Fork Pins and Guides X L Lubricate as
necessary.
See NOTE 2.
Use multipurpose
grease.
See NOTE 1.
10 Hydraulic Tank
Breather
X C Clean or Replace.
See NOTE 2.
See Parts Manual.
17 Integral Sideshift
Carriage
(Upper/Lower
Bearings)
X Check wear.
4 bearings.
See NOTE 5.
2.5 mm (0.098 in.)
minimum thickness.
17 Integral Sideshift
Carriage
Lower Mounting
Hooks
X Check for Wear
and Clearance.
See NOTE 2.
0.76 mm (0.03 in.)
minimum wear
limit.
8 Contactors X Check condition.
See Parts Manual.
See NOTE 12.
6 Steering King Pins L 4 fittings,
lubricate as
required.
See NOTE 2.
Use multipurpose
grease.
See NOTE 1.
7 Steering Tie Rods L 4 fittings,
lubricate as
required.
See NOTE 2.
Use multipurpose
grease.
See NOTE 1.
X=Check C=Change L=Lubricate CIL=Check Indicator Light during operation
8000 SRM 1541 Maintenance Schedule
