Description 2200 SRM 514
Table 1. Instrument Cluster, Internal Combustion (Continued)
Item
No.
Item Function
2
Coolant
Temperature Gauge
CAUTION
Do not continue to operate the lift truck
when the gauge indicates that the engine is
too hot (needle in the red zone).
This gauge indicates engine coolant temperature
when the key is in the ON position. During
normal operation, the gauge needle will be in
the green area. The sending unit for the coolant
temperature gauge is in the cylinder head. If
the temperature gauge does not work, check the
wiring or replace the sending unit or gauge. To
check the wiring, see the service manual section
for Diagrams.
3
Hourmeter The hourmeter operates when the key is
in the ON position. Periodic Maintenance
recommendations are based on these hours.
4
Left-Hand Turn
Indicator (Optional)
The light is on when the turn indicator lever is
in the left turn position.
5
Warning Light,
Alternator
CAUTION
Do not continue to operate the lift truck if
the red light is ON at engine speeds above
idle.
The light will be ON when the key is in the ON
position and the engine is not running and must
go OFF when the engine is running. If the light
does not function correctly, check the alternator
as described in the section for the Electrical
System 2200 SRM 560. To check the wiring, see
the service manual section for Diagrams.
6
Warning Light,
Transmission Oil
Temperature
CAUTION
Do not continue to operate the lift truck if
the red light is ON.
The red light is ON when the key is in the START
position and must go OFF whentheengineis
running. The sending unit for the temperature
light is at the bottom of the transmission housing,
on the front side. If the temperature light does
not work, check the wiring or replace the sending
unit or light. To check the wiring, see the service
manual section for Diagrams.
2
