2200 SRM 514 Description
Table 1. Instrument Cluster, Internal Combustion (Continued)
Item
No.
Item Function
7
Warning Light,
Engine Oil Pressure
CAUTION
Stop the engine immediately if the red light
is ON while the engine is running.
The red light is ON when the key is in the ON
position and the engine is not running and must
go OFF when the engine is running. The sending
unit for the warning light is in the engine block.
If the warning light does not work, check the
wiring or replace the sending unit or light. To
check the wiring, see the service manual section
for Diagrams.
8
Warning Light,
Brake Fluid Level
CAUTION
Do not continue to operate the lift truck if
the light is ON during operation.
The red light is ON when the key is in the START
position and must go OFF when the engine is
running. If the light is ON whentheengineis
running, the brake fluid level in the reservoir is
low. There is a float in the master cylinder that
actuates the warning light. If the light does not
work, check the wiring or the master cylinder or
replace the light. To check the master cylinder,
see the service manual section for the Brake
System. To check the wiring, see the service
manual section for Diagrams.
9
Warning Light,
Coolant Level in
the Radiator
CAUTION
Do not continue to operate the lift truck if
the light is ON during operation.
The red light is ON when the key is in the START
position and must go OFF when the engine is
running. If the light flashes when the engine is
running, the level of the coolant in the radiator
is too low. The sending unit for the warning light
isinthetopoftheradiator.Ifthewarninglight
does not work, check the wiring or replace the
sending unit or light. To check the wiring, see the
service manual section for Diagrams.
3
