Important Installation Steps for the HYTORC Washer
• Slide bolts through the bolt hole.
• Determine which side of the connection is more suitable for fastening and tightening the bolts.
(Working space for bolting, lighting, accessibility).
• Install the clean, dry nut on the opposite side from which you want to tighten.
• Now install the lubricated nut (on the same side as the HYTORC Washer) by turning it clockwise
until it is hand tightened against the HYTORC Washer.
HYTORC Washer Installed
CAUTION
For a correct installation only 3 to 4 threads should be seen beyond the nut to
be tightened.
Once all the bolts are prepared following the previous instructions for assembly, tighten the nuts using
the HYTORC Washer Driver.
24
BREAKTHROUGH PRODUCTS FOR INDUSTRIAL BOLTING
