Tightening with HYTORC Washer
• Put the tool in tightening mode.
• Put the tool in HYTORC Washer mode.
• Place the HYTORC Washer Driver on the Digital jGun and tighten the set screw.
• Engage the HYTORC Washer Driver and tool with the nut by placing it over the top of the bolt to
be tightened.
• Repeat the steps for tightening a bolt as shown for standard torque in this manual.
DIGITAL jGUN MAINTENANCE AND
TROUBLESHOOTING TIPS
1. Never exceed the maximum air pressure specied.
2. Check the female coupler on your unit’s hose and the male coupler on your Digital jGun for dirt.
Dirt entering your Digital jGun will result in air motor damage.
3. Check your Digital jGun’s gear box for loose or missing screws. DO NOT operate if any screws
are loose or missing, or serious damage may occur. Use LOCTITE 262 on screws.
4. Check your Digital jGun’s back cover gasket for air leaks. An air leak will result in
inaccurate torque.
Tightening HYTORC Washer™ Set Screw
26
BREAKTHROUGH PRODUCTS FOR INDUSTRIAL BOLTING
