6 Operation
6.1 Inspections before use
Make sure that:
• the oil level in the oil tank is beween the minimum mark and the maximum mark.
• the power supply is correct.
• the power cable is fully unrolled and not kinked, twisted or damaged.
• the remote control cable is fully unrolled and not kinked, twisted or damaged.
• all couplings and other connections are tight and not damaged or deformed.
• the hydraulic hoses are securely connected and not kinked, twisted or damaged.
Inspect the hydraulic hoses for damage with a set pressure of 200 bar (2,900 psi), 400
bar (5,800 psi) and 700 bar (10,000 psi) respectively.
• all moving parts of the tool are clean and sufficiently lubricated with a high-quality
NLGI #2 molybdenum disulfide grease. For subsea applications, HYTORC
recommends Womi lube.
• the square drive and the drive retainer are securely fitted.
• the reaction arm is placed against a solid reaction point and secured to the tool.
• the socket has the correct size and is secured to the tool.
• all securing clips, securing pins and securing screws are fitted and secured to the
pump unit, the hydraulic hoses, the tool, the reaction arm and the socket.
• all water, if present, is drained from the water separator (pneumatic pump units only).
• the pressure gauge does not leak. Signs of leakage are a decrease in the level of
glycerin in the pressure gauge or the pressure gauge filled with hydraulic oil.
6.2 Remote control
6.2.1 Electric pump unit
Procedure
1. Press the start button (A) on the
remote control to switch on the
pump unit.
2. Press and hold the start button (A)
on the remote control to increase
the pressure in the pump unit and
operate the tool.
3. Press the stop button (B) on the
remote control to switch off the
pump unit.
